DeepCool Power Supply DP-GD-DQ850-M-V2L DQ850-M-V2L US 850W ATX 12V 80+ GOLD Retail
DQ850-M-V2L
Reliable 80 PLUS Gold Efficiency
The DQ850-M-V2L fully modular 850W 80 PLUS Gold power supply features 100% Japanese capacitors and high quality switch MOSFETs. Built to deliver stable output capacity with high conversion efficiency, the DQ850-M-V2L offers better reliability for your PC system.
80 PLUS Gold Certified
Get all the power you need with a maximum 91.2% efficiency to reduce excess energy consumption and waste heat.
Top-notch Design
Featuring active Power Factor Correction (PFC), a full bridge LLC resonant converter and synchronous rectification DC-DC design, the DQ850-M-V2L delivers improved performance with lower power dissipation, increased quality, and better thermals to meet your needs.
80 PLUS Gold
80 PLUS Gold certified - Up to 87-90% efficient (20-100% Loading)
Silent and High Performance Fan
120mm silent fan has temperature control function to keep low noise
| Model DQ850-M-V2L |
| Type ATX 12V V2.31 |
| Certifications 80PLUS GOLD |
| Output Capacity 850W |
| Input Voltage 100-240V |
| Input Current 12.0A |
| Input Frequency Range 47-63Hz |
| Fan Size 120mm |
| PFC Active |
| Power Good Signal 100-500ms |
| Hold Up Time more than 16ms (80% Loading) |
| Efficiency more than 90% Under Typical Load (50% Loading) |
| Standby Efficiency ErP Lot 3 2014 |
| Protection OVP/UVP/OCP/SCP/OPP/OTP |
| Operation Temperature 0-40oC |
| Regulatory CE/CB/CCC/EAC/FCC/KCC/RCM/RoHs |
| MTBF 100,000 Hours |
| Item Dimension (L"xW"xH") 12 x 9 x 5 Weight 6.48 lbs Warranty Information 10 Years |
DeepCool DP-GD-DQ850-M-V2L DQ850-M-V2L 850W 12V 80+ GOLD
- Product Code: DeepCool DP-GD-DQ850-M-V2L DQ850-M-V2L 850W 12V 80+ GOLD
- SKU: 10242
- Live availability: Check
-
$166.49
