EVGA 500 GD 100-GD-0500-V1 500 W ATX12V / EPS12V 80 PLUS GOLD Certified Non-Modular Active PFC Power Supply

80 PLUS Gold certified, with 90% efficiency or higher under typical loads
Single 12V. Rail, DC-DC Converter to improve 3.3V. / 5V. Stability
Active Power Factor Correction
5 Year Warranty and unparalleled EVGA Customer Support
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
General
Brand EVGA
Series 500 GD
Model 100-GD-0500-V1
Details
Type ATX12V / EPS12V
Maximum Power 500 W
Fans 1 x 120mm Sleeve Bearing Fan
PFC Active
Main Connector 24Pin
+12V Rails Single
PCI-Express Connector 2 x 6+2-Pin
SATA Power Connector 6
Haswell Support Yes
Modular Non-Modular
Efficiency 90% or higher (under typical load)
Energy-Efficient 80 PLUS GOLD Certified
Over Voltage Protection Yes
Input Voltage 110 - 240 V
Input Frequency Range 50/60 Hz
Input Current 7 - 3A
Output +3.3V@20A, +5V@20A, +12V@41.6A, +5Vsb@2.5A, -12V@0.3A
MTBF 100,000 Hours
Approvals TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS, Compliance with ErP Lot 3 2014 Requirement
Max PSU Length 140 mm
Connectors 1 x 24 Pin ATX
1 x 8 Pin EPS (4+4)
2 x 8 Pin PCIe (6+2)
6 x SATA
3 x Four-Pin Peripheral
1 x Floppy
Features
Features The EVGA GD Series of power supplies builds upon a Solid Gold Foundation. Available in 700W, 600W and 500W, these power supplies are engineered to reach the same level of performance as EVGA's top-end gold units, but at a great value. Featuring 80 Plus Gold certified efficiency and a mainboard Japanese capacitor, the EVGA GD Series is a great choice for those looking for a great quality power supply at a great price.

Quiet and Intelligent Auto Fan for near-silent operation

80 PLUS Gold certified, with 90% efficiency or higher under typical loads.

Heavy-duty protections, including OVP (Over Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
Dimension & Weight
Dimensions 3.34" x 5.51" x 5.91"
Weight 3.70 lbs.

Details
Type	ATX12V / EPS12V
Maximum Power	500 W
Fans	1 x 120mm Sleeve Bearing Fan
PFC	Active
Main Connector	24Pin
+12V Rails	Single
PCI-Express Connector	2 x 6+2-Pin
SATA Power Connector	6
Haswell Support	Yes
Modular	Non-Modular
Efficiency	90% or higher (under typical load)
Energy-Efficient	80 PLUS GOLD Certified
Over Voltage Protection	Yes
Input Voltage	110 - 240 V
Input Frequency Range	50/60 Hz
Input Current	7 - 3A
Output	+3.3V@20A, +5V@20A, +12V@41.6A, +5Vsb@2.5A, -12V@0.3A
MTBF	100,000 Hours
Approvals	TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS, Compliance with ErP Lot 3 2014 Requirement
Max PSU Length	140 mm
Connectors	1 x 24 Pin ATX 1 x 8 Pin EPS (4+4) 2 x 8 Pin PCIe (6+2) 6 x SATA 3 x Four-Pin Peripheral 1 x Floppy

Features
Features	The EVGA GD Series of power supplies builds upon a Solid Gold Foundation. Available in 700W, 600W and 500W, these power supplies are engineered to reach the same level of performance as EVGA's top-end gold units, but at a great value. Featuring 80 Plus Gold certified efficiency and a mainboard Japanese capacitor, the EVGA GD Series is a great choice for those looking for a great quality power supply at a great price. Quiet and Intelligent Auto Fan for near-silent operation 80 PLUS Gold certified, with 90% efficiency or higher under typical loads. Heavy-duty protections, including OVP (Over Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)

Dimension & Weight
Dimensions	3.34" x 5.51" x 5.91"
Weight	3.70 lbs.
