Intel Core i9-14900KF - Core i9 14th Gen 24-Core (8P+16E) LGA 1700 125W None Integrated Graphics Processor - Boxed - BX8071514900KF
| Brand | Intel |
|---|---|
| Processors Type | Desktop |
| Series | Core i9 14th Gen |
| Name | Core i9-14900KF |
| Model | BX8071514900KF |
| CPU Socket Type | LGA 1700 |
|---|---|
| Core Name | Raptor Lake |
| # of Cores | 24-Core (8P+16E) |
| # of Threads | 32-Threads |
| Operating Frequency | Performance-core Base Frequency: 3.2 GHz Efficient-core Base Frequency: 2.4 GHz |
| Max Turbo Frequency | Intel Thermal Velocity Boost Frequency: Up to 6.0 GHz Intel Turbo Boost Max Technology 3.0 Frequency: Up to 5.8 GHz P-core Max Turbo Frequency: Up to 5.6 GHz E-core Max Turbo Frequency: Up to 4.4 GHz |
| L2 Cache | 32MB |
| L3 Cache | 36MB |
| Manufacturing Tech | Intel 7 |
| 64-Bit Support | Yes |
| Hyper-Threading Support | Yes |
| Memory Types | DDR4 3200 / DDR5 5600 |
| Memory Channel | 2 |
| Max Memory Size | 192 GB |
| Max Memory Bandwidth | 89.6 GB/s |
| Virtualization Technology Support | Yes |
| Integrated Graphics | None Integrated Graphics |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 / 4.0 |
| PCI Express Configurations | Up to 1x16+4, 2x8+4 |
| Max Number of PCI Express Lanes | 20 |
| Thermal Design Power | 125W |
| Max Turbo Power | 253W |
| Cooling Device | Cooling device not included - Processor Only |
| Compatible Desktop Chipsets | Intel H610 / Intel H670 / Intel B660 / Intel Q670 / Intel W680 / Intel Z690 / Intel H770 / Intel B760 / Intel Z790 * BIOS update may be required when used with some old chipset motherboard |
| Operating System Supported | Linux / Windows 10 (22H2, 21H2) / Windows 11 (22H2, 21H2) |
| Advanced Technologies | Intel Gaussian & Neural Accelerator: 3.0 Intel Thread Director Intel Deep Learning Boost (Intel DL Boost) on CPU Intel Speed Shift Technology Intel Adaptive Boost Technology Intel Thermal Velocity Boost Intel Turbo Boost Max Technology 3.0 Intel Turbo Boost Technology: 2.0 Intel Hyper-Threading Technology Intel 64 Instruction Set: 64-bit Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Enhanced Intel SpeedStep Technology Thermal Monitoring Technologies Intel Volume Management Device (VMD) |
Intel Core i9-14900KF - 24-Core (8P+16E)
|
